High temp H120 Black Mineral Wool
Quick Details:
- Packing: Heat-shrinking packing
- Density: 60kg-128kg
- Thickness: 25mm-150mm
- Delivery time: 7-15 days
- Payment terms: TT, LC, Westunion, Bitcoin, Trade Assurance
Get A Quote
Ecoin fire seal high temperature mineral wool is a kind of insulating material which is exclusively used for fire blockage. It is dark brawn(the color of iron ore) with all properties of mineral wool, with its melting point turbidity exceeding 1150℃. As a high-performance fireproof material for curtain wall, it has a resistance to shrinkage under high temperature better than that of similar mineral wool products.
Standard Sizes
| Nominal Density(KG) | 60 | 80 | 110 | 128 |
|---|---|---|---|---|
| Size: L*W(mm) | 1200*600 | |||
| Thickness(mm) | 100-150 | 50-120 | 50-120 | 50-100 |
Remarks: Other sizes available upon request.
Technical Parameters
| Propertities | Value | Unit | Standard |
|---|---|---|---|
| Fire Endurance | 1-4 | Hours |
AS 1530.4-1997/ISO 834 ASTM E119/JIS A1304 BS 476: Pt22 |
| Smoke Spread Index | 5 | – | ASTM E84/UL 723 |
| Flame Spread Index | 0 | – | ASTM E84/UL 723 |
| Combustion Performance | Non-combustible
Reation to fire-Class A1 |
– | ENISO1182
EN13501-1 |
| Thermal Conductivity (Average Temp 20℃) | 0.036-0.039 | W/mk | ASTM C518
GB/T 19686-2005 |
| Melting Point | ＞1000 | ℃ | – |
| Moisture Absorption | ≤0.04 | % by Vol | ASTM C1104 |
| Water absorption | ＜0.5 | kg/m2 | EN 1609 |
ECOIN high temperature H120 black mineral wool has below features:
High melting point; 1-4hr fire endurance
Non-conbustible material without generation of toxic fumes
Resistance to shrinkage under high temperature
Persistance thermal insulation performance
Safe, healthy, and environmental-friendly
Easy cutting and convenient application
ECOIN fire seal mineral wool board can effectively control the spread of flames and hot air currents by mean of fire resistance and blockage by the gap between curtain wall and structural floor or partition as well as ambient facilities such as chute that runs through floor or partition, thus forming fire barrier and dividing building into several areas to form passive fire blockage which remains effective for up to four hours at the most
applicable to thermal insulation and fire prevention of windowsill wall. As a passive fireproof structure of curtain wall, it can prevent the spread of flames from window to upper or adjacent units in case of fire through enhancing fire compartmentation effect of the wall between upper and lower windows.
It can be used for fire blocking of irregular gap.
